Mastervolt CombiMaster 24/3500-100 Inverter/Charger, 120 V

The CombiMaster 35523500 combines a true sine wave inverter, battery charger and AC transfer system in one enclosure. This 24 V model supplies 3,500 W continuously at 104°F (40°C) and provides up to 100 A of battery charging at 28.5 V. It supports automatic synchronization with the AC input and communicates through MasterBus or CZone.

Scalable configurations

The 24/3500-100 supports up to seven units in a single-phase parallel system rated at 120 V / 24.5 kW. Parallel and split-phase installations require matching model numbers, product codes and firmware versions, one shared battery bank sized for the application, and the installation procedures in the manufacturer manual. Use AC cables of equal gauge and length and DC cables of equal gauge and length to every unit; install the units no more than 1 ft apart. Multi-unit installation requires a qualified electrical technician.

Battery and installation requirements

Use in permanent systems with flooded, AGM or gel lead-acid batteries, or Mastervolt lithium-ion rechargeable batteries. The manufacturer recommends 200–1,000 Ah battery capacity for this model. Charging settings must meet the battery manufacturer's recommendations; user-defined settings require MasterAdjust or the CZone Configuration Tool. The charger uses Mastervolt 3-step+ charging and supports temperature compensation with the included battery temperature sensor.

Protect the inverter/charger from rain, snow, spray and condensing moisture. Output is temperature dependent: it delivers 1,750 W at 140°F (60°C) and shuts down above 140°F (60°C). Follow the complete manufacturer safety, wiring and configuration instructions.

Specifications
Model / product code CombiMaster 24/3500-100 (120 V) / 35523500
Nominal battery voltage / DC input range 24 V / 20–32 VDC
AC output 120 V, true sine wave; 50/60 Hz configurable
Continuous inverter power at 77°F (25°C) and 104°F (40°C) 3,500 W
Continuous inverter power at 140°F (60°C) 1,750 W; shutdown above 140°F (60°C)
Maximum peak load 150% for 10 seconds; 200% for 5 seconds
Maximum inverter efficiency 93%
Charger AC input 90–130 V; charging derates below 110 V
Maximum charger AC input current 32 A
Maximum battery charging current at 104°F (40°C) 100 A at 28.5 V
Recommended battery capacity 200–1,000 Ah
Single-phase parallel configuration Up to 7 identical 24/3500-100 units: 120 V / 24.5 kW
Synchronization Automatically synchronizes with the AC input
Communications MasterBus and CZone
