Discover ESS Battery Module 5.0 KWH 51.2V 100 AH, Heated 48-48-5120-H
Discover ESS Battery Module 5.0 KWH 51.2V 100 AH, Heated 48-48-5120-H

Discover ESS Battery Module 5.0 KWH 51.2V 100 AH, Heated 48-48-5120-H

Price: $1,590.00 USD
List Price: $1,999.00 USD
Price: $1,590.00 USD
You save: $409.00 (20%)
View Cart

Bulk Discount

Buy 3 or more items and receive 5% off this order! Discount will be automatically applied at checkout.

Commercial Pricing

Email us or call/text 415-877-4201 for your custom quote!

Shipping & Delivery

Shipping options and rates are calculated at checkout. Large, heavy, or freight items may ship separately or require confirmation before fulfillment.

Interest-Free Financing

Checkout and pay with Affirm, PayPal Pay in 4, Sezzle or Shop Pay Installments.

Estimated Arrival: Between Aug 01 and Aug 12.

SAVE $10 on orders over $200 | Use Coupon Code: KEEP10

00 Days
00 Hours
00 Minutes
00 Seconds

Discover ESS Battery Module, 5.0 KWH, 51.2V, 100 AH, Heated, 3U 19 inch

AES RACKMOUNT is the rapid install energy storage system designed for Residential Off-Grid Solar and Whole-Home Backup Power. The battery features a high-current GEN-4 BMS that delivers superior peak power for demanding load support, 1C charge/discharge rates and self-heating allowing for cold charge functionality. Easy configuration, UL1973 and UL9540-BESS enable seamless permitting throughout North America. An industry-leading 10-year warranty and energy throughput performance guarantee delivers a strong ROI.

Features

LYNK PORT

  • Connect battery string to LYNK Gateway
  • Multi-battery BMS communication
  • Remote ON/OFF capability

HIGH-CURRENT BMS

  • High peak surge, continuous current
  • Sets charge voltage, broadcasts SoC and temperature, balances cells

HEATED

  • Integrated self-heating

LYNK ACCESS

  • Monitor and troubleshoot
  • Configure communication with charger
  • Export battery data logs
  • Update battery firmware
ACCESSORIES

LYNK GATEWAY

  • Closed-loop charger configuration
  • J1939 / CAN Open / Serial CAN
  • Three programmable relays

ELEMENT ESS BATTERY COMBINER

  • Fully assembled. Quick connect cables
  • 19-inch rack mount
  • Combine up to 6 Battery Modules
  • Disconnect breaker
  • System ON/OFF button
BENEFITS

RUNS LONGER

  • 2x Runtime of lead-acid batteries
  • Up to 100% usable capacity

LASTS LONGER

  • 10x the life of lead-acid battery (BCI-06)
  • 10-Year warranty and energy performance guarantee

CHARGES FASTER

  • 1C max charge rate, regardless of SoC
  • 2x faster than C/2 rated Lithium batteries

SURGE POWER

  • Up to 2.2C peak power
  • Up to 1C charge/discharge

HIGH-EFFICIENCY

  • Up to 50% more energy efficient than lead-acid batteries
  • Up to 98% round-trip efficiency

DYNAMIC CHARGING

  • Up to 40% faster recharge from 0% to 100% SoC
  • Real-time charge rate optimization

PARALLEL POWER

  • Up to 160 kWh (per LYNK)
  • Linear scaling of charge, discharge, peak capacity

CERTIFICATION STANDARDS

  • IEC 62619
  • UL 1973
  • UL 9540a (pending)
  • UL9540 (pending)
  • CE
SHIPPING CLASSIFICATION
  • UN 38.3
  • UN 3480, Class 9 (Lithium batteries)
